| Display Specifications | |
| Display | 15″ Color TFT Open frame LCD monitor with protective glass |
| Model Name | AXD-15OPIP1-VP |
| Active Display Area (mm) | 304.1(H)x304.1(V) |
| Pixel Pitch (mm) | 0.297(H)x0.297(V) |
| Resolution (Pixel) | XGA (1024X768) 262K/16.2M Color |
| Brightness (CD/m^2) | 400cd/m^2 |
| Contrast Ratio | 800:1 |
| Viewing Angle (CR >=10) | 160/160 |
| Power consumption | 8.6 W typical, normal operation |
| Touch Screen | 5 wire Resistive touch USB options(no touch ,only glass) |
| OSD Control | On the back side |
| I/O Connectors | 1x12v,1XVGA,DVI-D |
| Power Input | DC 12V,4A 48W |
| Mechanical Specifications | |
| Construction | Steel Metal chassis & Black Color |
| Dimensions | 364.1 x 288.0x 40.0 (mm) |
| Mounting | VESA Mounting 75×75 |
| Power source | AC 100~240V/ 12V DC adapter |
| Environment Specifications | |
| Operating Temperature | -20~80ºC |
| Storage Temperature | -30~85ºC |
| Rating | Facilitate installation of the demolition,solid portfolio |
Quick Details
| Model: AXD-15OPIP1-VP | Screen Size:15” |
| Screen format: 4:3 | Display Resolution(pixel):1024×768 |
| Contrast Ratio:800:1 | Brightness:400cd/m^2 |
| Storage temperature : -30ºC~85ºC | Input signal: VGA DVI-D |
| Power Input: DC 12V Glass Type: 2mm anti vandal glass with touch |
Product status: custom |
Features and Advantages
1. New and Industrial A grade perfect panels with stable supply
2. Slim and simple panel mount all the LCD kits in one , which is easily installed
3. industrial control board supports the displays working 24 hours,-30-85 degrees
4. Professional and industrial hardware and parts to guarantee its working normally in rough environment
5. VGA DVI interfaces ; touch screen options
6. 15 inch open frame monitor with protective for application control , advertising player ,campus and industrial terminals etc
