| Panel PC information | |
| Model Number | AXD-15PPC-A7C |
| 15” Industrial panel mount panel pc | |
| Case/Bezel Color | Black |
| TFT Type | Industrial LCD with LED backlight |
| Aspect ratio | 4:3 |
| Touch Panel | Industrial Projected-capacitive Flat Screen |
| Touch response time | 10ms (typical) |
| Optimal (native) Resolution | 1024×768 |
| LCD panel Pixel pitch | 0.296 x 0.296 mm |
| LCD panel Colors | 16.7million |
| LCD panel Brightness | 400cd/m2 |
| LCD panel Response Time | 8ms |
| Contrast Ratio | 1300:1 |
| Viewing Angle ( Wide ) | |
| Horizontal (left/right) | ±88° or 176° total |
| Vertical (up/down) | 88°(up), 88°(down) or 176° total |
| CPU | Intel® I5-3317U |
| storage | 64G SSD |
| Serial Ports | 2x COM ports |
| USB Ports | 3 x USB |
| LAN | 1 x LAN RJ-45 connector |
| DC Power In | 1 x 4-pin connector |
| Video Port | 2X Audio |
| Other Ports | 2x LAN, 1XVGA,1xHDMI,1XLPT |
| Internal Sockets & Connectors | 1 x Compact Flash socket (reserved for OEM project) |
| Power Specification | DC 12V |
| Working Environment | |
| Temperature | Operating: -10°C to 60°C ;Storage -20°C to 70°C |
| Operating Humidity | 5 ~ 90% RH @40°C (non-condensing |
| Vibration | 5 ~ 500Hz, 3Grms Random (with CF/SSD) |
| Dimensions | |
| Mounting Type | Embedded Installation |
| Mechanical dimensions | 355.8 x 287.3 x 62.4 mm |
| Weight (Net) | 6.5 kgs/ piece |
| Drawings | Please contact us for details |
