| Model Number | AXD-19OPPC-VI3 |
| 19” Open Frame built panel pc | |
| Case/Bezel Color | white |
| TFT Type | Industrial LCD with LED backlight |
| Aspect ratio | 4:3 |
| Touch Panel | Industrial 5 wire Resistive Flat Screen optional |
| Touch response time | 8ms (typical) |
| Optimal (native) Resolution | 1280X1024 |
| LCD panel Pixel pitch | 0.297 x 0.297 mm |
| LCD panel Colors | 16.7 million |
| LCD panel Brightness | 350 cd/m2 |
| LCD panel Response Time | 5ms |
| Contrast Ratio | 1000:1 |
| Viewing Angle ( Wide ) | |
| Horizontal (left/right) | ±85° or 170° total |
| Vertical (up/down) | 80°(up), 80°(down) or 160° total |
| CPU | Intel® Processor I3 (1.8GHz) |
| storage | 4G /8G RAM;SSD 64G/128 G Options |
| Serial Ports | 2 x COM ;RS232/RS485 |
| USB Ports | 2x USB V2.0; 2xUSB V3.0 |
| LAN | 1 x LAN RJ-45 connector |
| DC Power In | 1 x DC2.5 connector |
| Video Port | 1X Line-out |
| Other Ports | 1x LAN, 1X VGA ,1xHDMI,1X Audio |
| Internal Sockets & Connectors | reserved for OEM project |
| Power Specification | DC 12V |
| Working Environment | |
| Temperature | Operating: -10°C to 60°C ;Storage -20°C to 65°C |
| Operating Humidity | 5 ~ 90% RH @40°C (non-condensing |
| Vibration | 5 ~ 500Hz, 3Grms Random (with CF/SSD) |
| Dimensions | |
| Mounting Type | Embedded Installation,wall mounting |
| Mechanical dimensions | 423.0 x 327 x 53.0 mm |
| Weight (Net) | 7.5 kgs/ piece, 1 piece/ carton |
| Drawings | Please contact us for details |
| Life span | > 50000 Hours |
| MTBF | 24X7 days |
| Packing details | 1x 19 inch Open frame Industrial Panel PC ; Packed in 3pieces/carton with protection foam Optional accessories:1x Power supply cable, 1x power adapter |
| Delivery terms | 7- working days for stock products after receiving payments; 15 working days for order production |
· Automatic system:intelligent self-service terminal, intelligent retail terminal, smart device, robot equipment, etc.
· Public Places: subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums,convention centers, ticket agencies;
· Organizations: supermarket, large-scale shopping malls, exclusive agency, chain shops, large-scale sales, star-rated hotels, restaurants, travel agencies, pharmacy; Telecommunications, post offices, hospital, schools
· Financial Organizations: Banks, negotiable securities, funds, insurance companies,etc
· Real Estate Property: Apartments, villas, offices, commercial buildings, etc.
· Entertainments: Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, etc
