| Display Specifications | |
| Display | 21.5 ” Color TFT wide display kits |
| Model Name | HR215WU1-120 |
| Active Display Area (mm) | 476.64 (H)x268.11(V) |
| Pixel Pitch (mm) | 248.25 (per one triad) x 248.25 |
| Resolution (Pixel) | WVGA (1920X1080)16.7M/6 bit + FRC |
| Brightness (CD/m^2) | 250cd/m^2 |
| Contrast Ratio | 1000:1 |
| Viewing Angle (CR >=10) | 178/178 |
| Power consumption | 18.8W typical, normal operation |
| Touch Screen | Resistive touch screen , please request if needed |
| OSD Control | only panel |
| I/O Connectors | LVDS PORT |
| Power Input | 12 DC |
| Mechanical Specifications | |
| Construction | industrial lcd panel |
| Dimensions | Subject to the updated drawings |
| Mounting | Edge fixing holes, Vesa Mounting |
| Power source | AC 100~240V/ 12V4AAC/DC adapter |
| Environment Specifications | |
| Operating Temperature | 0~50ºC |
| Storage Temperature | -20~60ºC |
| Rating | Facilitate installation of the demolition,solid portfolio |
Features and Advantages
1. New and original A grade perfect panels with 1920×1080 high resolution
2. If you need our industrial control board supports the displays working 24×7 days, we could also provide the panel kits for you.
