| Display Specifications | |
| Display | 21.5″ Open frame Monitor IPS |
| Model Name | AXD-21OPN1P1-VH3 |
| Active Display Area (mm) | 476.64 (H)x268.11(V) |
| Pixel Pitch (mm) | 0.282(H)x0.282(V) |
| Resolution (Pixel) | WSXGA (1920X1080) |
| Brightness (CD/m^2) | 1000cd/m^2 |
| Contrast Ratio | 1000:1 |
| Viewing Angle (CR >=10) | 89/89/89/89 super wide viewing angle |
| Power consumption | 33.6 W typical, low consumption ,normal operation |
| Touch Screen | Resistive RS232/USB(Optional) |
| OSD Control | On the back side |
| I/O Connectors | 1x12v,1XVGA,DVI-D(Optional) |
| Power Input | DC 12V,4A 48W |
| Mechanical Specifications | |
| Construction | Steel metal housing |
| Dimensions | 522.0x 294.6x 33.0(mm) |
| Mounting | Embedded ,fixing holes on the edging frame |
| Power source | AC 100~240V/ 12V DC |
| Environment Specifications | |
| Operating Temperature | 0~60ºC |
| Storage Temperature | -20~60ºC |
| Rating | Facilitate installation of the demolition,solid portfolio |
| Ordering Information | 21.5″ 1000nits Open frame FHD IPS Technology with VGA input and power adapter |
