| Panel PC information | |
| Model Number | AXD-21PPC-V3 |
| 21.5’’ Touch panel pc | |
| Case/Bezel Color | Black |
| TFT Type | Industrial LCD with LED backlight |
| Aspect ratio | 16:9 |
| Touch Panel | Industrial Multi-touch IR Flat Screen |
| Touch response time | 8ms (typical) |
| Optimal (native) Resolution | 1920X1080 |
| LCD panel Pixel pitch | 0.2482 x 0.2482mm |
| LCD panel Colors | 16.7 million |
| LCD panel Brightness | 250 cd/m2 |
| LCD panel Response Time | 8ms |
| Contrast Ratio | 1000:1 |
| Viewing Angle ( Wide ) | |
| Horizontal (left/right) | ±85° or 170° total |
| Vertical (up/down) | 85°(up), 85°(down) or 170° total |
| CPU | Intel® I3-7200U 2.4G |
| storage | 32 G/64G/128G SSD ( optional) |
| Serial Ports | 1 x COM port internal |
| USB Ports | 2 x USB 3.0 ports, can expand |
| LAN | 1 x LAN RJ-45 connector |
| DC Power In | 1 x 4-pin connector |
| Video Port | 1X Line-out ( S/ PDIF), 1XMic- in |
| Other Ports | 1x LAN, 1X DVI-D,1xHDMI,1X e SATA (2.0) |
| Internal Sockets & Connectors | 1 x PCI-E sockets (reserved for OEM project) |
| Power Specification | DC 12V/24V Options |
| Working Environment | |
| Temperature | Operating: 0°C to 50°C ;Storage -30°C to 65°C |
| Operating Humidity | 5 ~ 90% RH @40°C (non-condensing |
| Vibration | 5 ~ 500Hz, 3Grms Random (with CF/SSD) |
| Dimensions | |
| Mounting Type | Embedded Installation |
| Mechanical dimensions | 560.0 x 370 x 80.7mm |
| Weight (Net) | 7.5 kgs/ piece, 3 pieces/ carton |
| Drawings | Please contact us for details |
