| Display Specifications | |
| Display | 26″ Color LED Industrial IR Touch Monitor |
| Model Name | AXD-26OPN1T1-VT4 |
| Active Display Area (mm) | 575.77(H)x 323.71(V) |
| Pixel Pitch (mm) | 0.4215(H)x 0.4215(V) |
| Resolution (Pixel) | 1366X768;1920X1080 262,144(6 bit + FRC) |
| Brightness (CD/m^2) | 400cd/m^2 |
| Contrast Ratio | 1500:1 |
| Viewing Angle (CR >=10) | 176/176 wide view angle |
| Power consumption | 28.5 W typical, normal operation |
| Touch Screen | IR anti-vandal ,water-proof, dust-proof touch |
| OSD Control | On the back side |
| I/O Connectors | 1x12v,1XVGA,DVI-D(Optional) |
| Power Input | DC 12V,4A48W Adapter |
| Mechanical Specifications | |
| Construction | Open frame steel metal material |
| Dimensions | 666.0x 376.2x 95.0(mm) |
| Mounting | Embedded ,right and left ; VESA 75×75(100×100) Wall Mounting Optional |
| Power source | AC 100~240V/ 12V DC |
| Environment Specifications | |
| Operating Temperature | 0~60℃ |
| Storage Temperature | -10~60℃ |
| Rating | Facilitate installation of the demolition, solid portfolio |
| Ordering Information | 26.0” OP LED IR touch Monitor with VGA input and power adapter |
