LCD monitor information |
|
|
Model Number |
AXD-07OPN1P1-T2 C |
|
7” Open Frame Touch LCD Monitor |
|
|
Type |
7 ” TFT Active Matrix LCD with LED Backlight |
|
Active Display Area(mm) |
154.08 (H) x 85.92 (V) |
|
Pixel Pitch(mm) |
0.0642 (H) x 0.1790 (V) |
|
Resolution |
800 x 480 |
|
Contrast Ratio |
500:1 (typ.) |
|
Display Color |
16.7 M colors |
|
Brightness |
500(Typ) |
|
Viewing Angles |
140(H);140(V) |
|
Response Time |
10ms/15ms |
|
Environmental Temperature |
|
|
Operating Temperature |
-30ºC~80ºC |
|
Storage Temperature |
-30ºC~85ºC |
|
Power Specification |
|
|
Voltage Consumption |
AC 100~240V,Universal,±10% ; AC/DC 12V4A |
|
5.3W typical, normal operation |
|
Touch Screen Optional |
G+G cover Glass |
|
touch panel type |
Pro-capacitive touch glass with eeti chipset |
|
Touch interface |
USB |
|
Transmittance |
>=85% |
|
Input voltage |
less than 10V |
|
working temperature |
-30~80ºC |
|
touch kits |
>=50,000,000 times in one position |
|
Dimensions |
|
|
Holes fixings |
Vesa mounting 75×75/ fixing holes on the right/left |
|
Mechanical dimensions |
208mmx124mmx31mm |
|
Drawings |
Please contact us for details |
Our Services:
1.Powerfull Research&Development Experience on every kind of touch monitors
2.OEM&ODM Ability
3.Strict QC TEST Control by axnew
4.EASY & FAST Communicate
5.Responsible After Service
Packaging & Delivery
|
Packing details |
1x 7 inch Industrial Touch Screen Monitor; Packed in 10 pieces/carton with protection foam Optional accessories: 1xVGA, 1x Power supply cable, 1x power adapter |
|
Delivery terms |
7- working days for stock products after receiving payments; 15 working days for order production |
