| Display Specifications | |
| Display | 26.0″ Color TFT high brightness LCD monitor |
| Model Name | AXD-26OPIPN1P-VH5 |
| Active Display Area (mm) | 580.2 (H)x328.2(V) |
| Pixel Pitch (mm) | 0.300(H)x0.300(V) |
| Resolution (Pixel) | 1366X768/1920X1080 |
| Brightness (CD/m^2) | 1000cd/m^2 |
| Contrast Ratio | 1200:1 |
| Viewing Angle (CR >=10) | 170/170 |
| Power consumption | 98 W typical, normal operation |
| Touch Screen | Resistive RS232/USB(Optional) |
| OSD Control | On the back side |
| I/O Connectors | 1x12v,1XVGA,DVI-D(Optional) |
|
Power Input Touch Screen options |
220v |
| Mechanical Specifications | |
| Construction | Steel metal housing |
| Dimensions | Drawings |
| Mounting | Embedded ,fixing holes on the |
| Power source | AC 100~240V/ 12V DC |
| Environment Specifications | |
| Operating Temperature | -10~70ºC |
| Storage Temperature | -20~80ºC |
| Rating | Facilitate installation of the demolition,solid portfolio |
| Ordering Information | 26″ High brightness LCD HD with 1000nits brightness monitor |
