Display Specifications | |
Display | 21.5″ Color TFT Sunlight readable monitor |
Model Name | AXD-21OPN1P1-VH3 |
Active Display Area (mm) | 476.64 (H) x 268.11 (V) |
Pixel Pitch (mm) | 0.2485 (H) x 0.2485 (V) |
Resolution (Pixel) | 1920X1080 |
Brightness (CD/m^2) | 1000cd/m^2 |
Contrast Ratio | 1000:1 |
Viewing Angle (CR >=10) | 178/178 |
Power consumption | 31.71 W typical, normal operation |
Touch Screen | NO ;Resistive, capacitive ;IR Touch ;RS232/USB(Optional) |
OSD Control | On the back side |
I/O Connectors | 1x12v,1XVGA,DVI-D |
Power Input | AC 100~240V,Universal,±10% ; AC/DC 12V4A |
Mechanical Specifications | |
Construction | Roasted Metal Frame |
Dimensions | 528.2x 295.2x 39.0(mm) |
Mounting | U Left-right fixing holes ,VESA 75×75(100×100) |
Power source | AC 100~240V/ 12V DC |
Environment Specifications | |
Operating Temperature | -5~50ºC |
Storage Temperature | -20~60ºC |
Rating | Facilitate installation of the demolition, solid portfolio |
Ordering Information | 21.5″ Sunlight readable Monitor 1000nits with full HD |
High Resolution High Brightness Monitor 21.5 Inch 1000 Nits with Dimmable Sensor
Brand :
ScreenSize:21.5”
Display Resolution(pixel):1920X1080
Contrast Ratio:1000:1
Brightness(CD/m^2):1000 cd/m2
Touch type: NO ;Resistive, capacitive ;IR Touch ;RS232/USB
