| Display | 10.4 inch industrial LCD screen |
| Active Area | 211.2(H)×158.4(V) |
| Backlight System | CCFL |
| Brightness | 350nits |
| Contrast Ratio | 600:1 |
| Charateristics | This high-contrast VGA module features brightness and contrast ratings of 300 nits and 600:1, respectively. The module also incorporates color filters optimized for excellent color performance, and anti-glare and 3H hard coatings. |
| Display Mode | Normally White |
| Interface | 6-bit (262,144 colors) |
| operating Temperature | -10ºC~65ºC |
| Outline dimensions | 246.5(W)×179.4(H)×14.2(D) |
| Resolution | 640×480 |
| Respons time | 35ms |
| RoHS | YES |
Features and Advantages
1. New and A grade perfect panels with LED backlight
2.10.4 inch high resolution open Kits are easily for installing in the Panel pcs, outdoor application control , digital player ,campus and industrial terminals etc
