| Display Specifications | |
| Display | 19″ Color TFT High Brightness Lcd Monitor |
| Model Name | AXD-19OPT4P1-VH2 |
| Active Display Area (mm) | 376.3 (H)x301.1(V) |
| Pixel Pitch (mm) | 0.294(H)x0.294(V) |
| Resolution (Pixel) | SXGA (1280X1024) 16.7 M |
| Brightness (CD/m^2) | 1000cd/m^2 |
| Contrast Ratio | 1000:1 |
| Viewing Angle (CR >=10) | 170/160 |
| Power consumption | 28.5W typical, normal operation |
| Touch Screen | IR Infrared touch panel anti-vandal Options |
| OSD Control | On the back side |
| I/O Connectors | 1x12v,1XVGA,DVI-D |
| Power Input | DC 12V,4A 48W |
| Mechanical Specifications | |
| Construction | Steel chassis |
| Dimensions | 430.0 x 280.0×35.5 (mm) |
| Mounting | fixing holes embedded |
| Power source | AC 100~240V/ 12V DC-4A |
| Environment Specifications | |
| Operating Temperature | -5~60ºC |
| Storage Temperature | -10~70ºC |
| Rating | Facilitate installation of the demolition, solid portfolio |
| Ordering Information |
19″High Brightness with VGA input and power adapter |
